Unilumin UMini W1.2

Name: Unilumin UMini W1.2
Brand: Unilumin

Steps up to 1.2 mm for rooms where people present standing right beside the screen.

Full specifications Typical wall sizes

Full specifications, dimensions and contact details on one page.

Front · 1/6

Cabinet front elevation — emitter grid and module seams drawn to scale.

Manufacturer product photography. Photography of the delivered installation is included in every project handover.

Unilumin on YouTube

Pixel pitch

P1.2

Brightness

700 nits

Refresh

3,840 Hz

Use

Indoor

How it connects

Your source to this wall

Every Unilumin wall we supply ships as a complete signal chain \u2014 including the NovaStar control layer most suppliers leave for you to figure out.

How it connects

source

Source (PC / player / camera)

processor

NovaStar H Series

controller

Sending & receiving cards

wall

Unilumin UMini W1.2

Engineering

Major features, part by part

Hover any numbered point to see what it does and why it matters on site.

Reference

Typical wall sizes

Cabinets, resolution, power and weight for common wall sizes built from the 600×337.5 mm Unilumin cabinet at P1.2.

Target size	Cabinets	Resolution	Actual size	Avg power	Weight
3 × 2 m	5 × 6 (30)	2500 × 1688 (4.2 MP)	3.00 × 2.02 m	0.8 kW	204 kg
4 × 2.5 m	7 × 7 (49)	3500 × 1969 (6.9 MP)	4.20 × 2.36 m	1.3 kW	333 kg
5 × 3 m	8 × 9 (72)	4000 × 2531 (10.1 MP)	4.80 × 3.04 m	1.9 kW	490 kg
6 × 3.5 m	10 × 10 (100)	5000 × 2813 (14.1 MP)	6.00 × 3.38 m	2.7 kW	680 kg
8 × 4.5 m	13 × 13 (169)	6500 × 3656 (23.8 MP)	7.80 × 4.39 m	4.6 kW	1149 kg
10 × 6 m	17 × 18 (306)	8500 × 5063 (43.0 MP)	10.20 × 6.08 m	8.3 kW	2081 kg

Cabinet counts are rounded to whole cabinets, so the actual size differs slightly from the target. Power is the average draw; size the supply on peak. Confirm structural loading against the manufacturer datasheet.

Recommended controlNovaStar H SeriesBeyond a single COEX controller — modular chassis, specified on the input list.NovaStar H Series →

Why this model

Seamless 16:9 tiling

Cabinets tile to exact 16:9 canvases — no odd edges or visible seams.

Beats a projector

Bright in lit rooms, no lamp changes, instant on.

Low-noise, low-heat

Fanless operation keeps meeting rooms silent.

Specifications

Display

Pixel pitch1.2 mm

LED typeSMD / flip-chip

Brightness700 nits

Refresh rate3,840 Hz

Colour depth14–16-bit

Viewing angle160° / 160°

Cabinet

Cabinet size600 × 337.5 mm

Resolution / cabinet500 × 281

Weight6.8 kg

Service accessFront

MountingFixed indoor

Power & environment

Avg power≈ 27 W / cabinet

Max power≈ 80 W / cabinet

IP ratingIP30 (indoor)

Lifespan100,000 hrs

Applications

BoardroomsLobbiesAuditoriumsPremium retail

FAQ

Better than a projector?

Yes — far brighter in daylight-lit rooms, no wash-out and no consumables.

Can it show a PC and video together?

Yes, with a processor you can window multiple live sources.

Will it look sharp?

Viewing distance & image quality

Minimum viewing distance

1.2 m

Closest a viewer should stand

Comfortable distance

3 m

Where the image looks its best

Pixels per m²

694,444

Density at this pitch

Brightness

700 nits

Comfortable indoors

Rule of thumb: minimum viewing distance in metres \u2248 pixel pitch in millimetres. Final figures confirmed on site survey.

What you actually receive

A complete system, not just panels

LED cabinets & modules

Unilumin UMini W1.2 · 600×337.5 mm

Control system

NovaStar H Series + receiving cards

Power & data cabling

Looms, distribution and redundancy

Mounting structure

Wall frame, floor stand or truss

Spare modules & PSU

Held in Kathmandu for fast swap

Commissioning

Calibration, content test, handover training

How we deliver it

Site survey

We measure the space, power and sightlines — free across Nepal.

Structure & install

Fabrication, mounting and cabling by our certified engineers.

Commissioning

Calibration, controller setup and operator training.

AMC & support

Annual maintenance with spares stocked locally.

Warranty

Up to 3 years

Honoured locally in Nepal

Indicative lead time

2\u20134 weeks

Ex-stock items ship faster

Certifications

CERoHSFCCISO 9001

Also consider

Unilumin

Umini III Pro

Unilumin's workhorse control-room panel: flip-chip COB, front-serviced, and the model we specify most often for 24/7 NOC walls.

P1.2indoor

Unilumin

Upanel 1.2

Standard-cabinet sibling to the Umini — same COB surface, easier to source and stock for larger multi-room rollouts.

P1.2indoor

Unilumin

Upanel AIO 1.2

Higher-resolution all-in-one for rooms where people read spreadsheets off the screen.

P1.2indoor

Model	Pitch	Brightness	Use	Cabinet
Unilumin UMini W1.2 (this model)	P1.2	700 nits	indoor	600\u00d7337.5 mm
Unilumin Umini III Pro	P1.2	650 nits	indoor	600\u00d7337.5 mm
Unilumin Upanel 1.2	P1.2	600 nits	indoor	600\u00d7337.5 mm
Unilumin Upanel AIO 1.2	P1.2	620 nits	indoor	600\u00d7337.5 mm
