Unilumin · Rental — Indoor Staging

Unilumin Upad IV Pro

Name: Unilumin Upad IV Pro
Brand: Unilumin

Tool-free quick-lock and a curve lock in the same panel — the standard indoor touring panel across Nepal's event companies.

Full specifications Typical wall sizes

Full specifications, dimensions and contact details on one page.

Front · 1/6

Cabinet front elevation — emitter grid and module seams drawn to scale.

Manufacturer product photography. Photography of the delivered installation is included in every project handover.

Unilumin on YouTube

Pixel pitch

P2.6

Brightness

1,200 nits

Refresh

3,840 Hz

Use

Rental

How it connects

Your source to this wall

Every Unilumin wall we supply ships as a complete signal chain \u2014 including the NovaStar control layer most suppliers leave for you to figure out.

How it connects

source

Source (PC / player / camera)

processor

NovaStar VX400

controller

Sending & receiving cards

wall

Unilumin Upad IV Pro

Engineering

Major features, part by part

Hover any numbered point to see what it does and why it matters on site.

Reference

Typical wall sizes

Cabinets, resolution, power and weight for common wall sizes built from the 500×500 mm Unilumin cabinet at P2.6.

Target size	Cabinets	Resolution	Actual size	Avg power	Weight
3 × 2 m	6 × 4 (24)	1154 × 769 (0.9 MP)	3.00 × 2.00 m	0.9 kW	168 kg
4 × 2.5 m	8 × 5 (40)	1538 × 962 (1.5 MP)	4.00 × 2.50 m	1.5 kW	280 kg
5 × 3 m	10 × 6 (60)	1923 × 1154 (2.2 MP)	5.00 × 3.00 m	2.3 kW	420 kg
6 × 3.5 m	12 × 7 (84)	2308 × 1346 (3.1 MP)	6.00 × 3.50 m	3.2 kW	588 kg
8 × 4.5 m	16 × 9 (144)	3077 × 1731 (5.3 MP)	8.00 × 4.50 m	5.5 kW	1008 kg
10 × 6 m	20 × 12 (240)	3846 × 2308 (8.9 MP)	10.00 × 6.00 m	9.1 kW	1680 kg

Cabinet counts are rounded to whole cabinets, so the actual size differs slightly from the target. Power is the average draw; size the supply on peak. Confirm structural loading against the manufacturer datasheet.

Recommended controlNovaStar VX400Compact staging load — one box scales, switches and sends.NovaStar VX400 →

Why this model

Tool-free quick-lock

Cabinets latch and align in seconds — hours off your get-in.

Curve-lock

Angle cabinets to build concave or convex stage arcs.

Flight-case ready

Protected corners and cases survive repeat touring.

Specifications

Display

Pixel pitch2.6 mm

LED typeSMD

Brightness1,200 nits

Refresh rate3,840 Hz

Colour depth14–16-bit

Viewing angle160° / 160°

Cabinet

Cabinet size500 × 500 mm

Resolution / cabinet192 × 192

Weight7 kg

Service accessFront

MountingGround-stack or flown

Power & environment

Avg power≈ 38 W / cabinet

Max power≈ 113 W / cabinet

IP ratingIP65

Lifespan100,000 hrs

Applications

ConcertsWeddingsCorporate eventsConferences

FAQ

Do you offer dealer rates?

Yes — Nepal event companies and rental houses get partner pricing and priority turnaround.

Are standby panels available?

We hold standby stock so a failed cabinet never stops a show.

Will it look sharp?

Viewing distance & image quality

Minimum viewing distance

2.6 m

Closest a viewer should stand

Comfortable distance

6.5 m

Where the image looks its best

Pixels per m²

147,929

Density at this pitch

Brightness

1,200 nits

Comfortable indoors

Rule of thumb: minimum viewing distance in metres \u2248 pixel pitch in millimetres. Final figures confirmed on site survey.

What you actually receive

A complete system, not just panels

LED cabinets & modules

Unilumin Upad IV Pro · 500×500 mm

Control system

NovaStar VX400 + receiving cards

Power & data cabling

Looms, distribution and redundancy

Mounting structure

Wall frame, floor stand or truss

Spare modules & PSU

Held in Kathmandu for fast swap

Commissioning

Calibration, content test, handover training

How we deliver it

Site survey

We measure the space, power and sightlines — free across Nepal.

Structure & install

Fabrication, mounting and cabling by our certified engineers.

Commissioning

Calibration, controller setup and operator training.

AMC & support

Annual maintenance with spares stocked locally.

Warranty

Up to 3 years

Honoured locally in Nepal

Indicative lead time

2\u20134 weeks

Ex-stock items ship faster

Certifications

CERoHSFCCISO 9001

Also consider

Unilumin

UpanelS 2.6

Same seam-free tiling as the fine-pitch UpanelS, at a signage-appropriate pitch and price.

P2.6indoor

Unilumin

Uslim III MIP 2.5

MIP packaging survives knocks in public spaces far better than exposed SMD — worth it in a mall concourse.

P2.5indoor

Unilumin

UDA 2.5

Built for retail: high brightness and a finish that stays legible under strong ceiling spots.

P2.5indoor

Model	Pitch	Brightness	Use	Cabinet
Unilumin Upad IV Pro (this model)	P2.6	1,200 nits	rental	500\u00d7500 mm
Unilumin UpanelS 2.6	P2.6	1,000 nits	indoor	640\u00d7480 mm
Unilumin Uslim III MIP 2.5	P2.5	1,000 nits	indoor	640\u00d7480 mm
Unilumin UDA 2.5	P2.5	1,050 nits	indoor	640\u00d7480 mm

The full Unilumin line

Unilumin product lines we supply

Unilumin's full range in Nepal — control-room fine pitch trusted by Aramco & JANAF, stadium USports, plus creative and rental — with genuine warranty and local install.

Control Room & Command

Upanel 1.2 · Upanel 1.5 · UpanelS 1.2 · UpanelS 1.5 · +6 more

10 models \u2192

Fine Pitch Indoor

Umicro · Umini III · Umini III Pro · Uslim III SMD · +1 more

5 models \u2192

Sports & Stadium (USports)

UsportX · UsportR · UsportMA II

3 models \u2192

Creative & Rental

U-Natural · Udesign SV · UHF · Umake OF Sphere · +3 more

7 models \u2192

Need a drawing, availability or the manufacturer datasheet for Unilumin Upad IV Pro?

Talk to an engineer →
