LED Display Nepal

Product specification sheet

leddisplaynepal.com

Evolve · All-in-One & Conference

Evolve AIO 1.2

Name: Evolve AIO 1.2
Brand: Evolve

Own-brand all-in-one, delivered and commissioned by our own team in Kathmandu.

Full specifications Typical wall sizes

Full specifications, dimensions and contact details on one page.

Front · 1/6

Cabinet front elevation — emitter grid and module seams drawn to scale.

Manufacturer product photography. Photography of the delivered installation is included in every project handover.

Pixel pitch

P1.2

Brightness

600 nits

Refresh

3,840 Hz

Use

Indoor

How it connects

Your source to this wall

Every Evolve wall we supply ships as a complete signal chain \u2014 including the NovaStar control layer most suppliers leave for you to figure out.

How it connects

source

Source (PC / player / camera)

processor

NovaStar MX30

controller

Sending & receiving cards

wall

Evolve AIO 1.2

Engineering

Major features, part by part

Hover any numbered point to see what it does and why it matters on site.

Reference

Typical wall sizes

Cabinets, resolution, power and weight for common wall sizes built from the 600×337.5 mm Evolve cabinet at P1.2.

Target size	Cabinets	Resolution	Actual size	Avg power	Weight
3 × 2 m	5 × 6 (30)	2500 × 1688 (4.2 MP)	3.00 × 2.02 m	0.7 kW	195 kg
4 × 2.5 m	7 × 7 (49)	3500 × 1969 (6.9 MP)	4.20 × 2.36 m	1.1 kW	319 kg
5 × 3 m	8 × 9 (72)	4000 × 2531 (10.1 MP)	4.80 × 3.04 m	1.7 kW	468 kg
6 × 3.5 m	10 × 10 (100)	5000 × 2813 (14.1 MP)	6.00 × 3.38 m	2.3 kW	650 kg
8 × 4.5 m	13 × 13 (169)	6500 × 3656 (23.8 MP)	7.80 × 4.39 m	3.9 kW	1099 kg
10 × 6 m	17 × 18 (306)	8500 × 5063 (43.0 MP)	10.20 × 6.08 m	7.0 kW	1989 kg

Cabinet counts are rounded to whole cabinets, so the actual size differs slightly from the target. Power is the average draw; size the supply on peak. Confirm structural loading against the manufacturer datasheet.

Recommended controlNovaStar MX30Permanent install — COEX keeps calibration in the controller for re-calibration years later.NovaStar MX30 →

Why this model

Plug and play

Arrives calibrated with built-in OS — power on and present.

Wireless presentation

Any laptop or phone to the screen in one tap.

One-day install

Standard sizes mount fast with no site fabrication.

Specifications

Display

Pixel pitch1.2 mm

LED typeSMD

Brightness600 nits

Refresh rate3,840 Hz

Colour depth14–16-bit

Viewing angle160° / 160°

Cabinet

Cabinet size600 × 337.5 mm

Resolution / cabinet500 × 281

Weight6.5 kg

Service accessFront

MountingFixed indoor

Power & environment

Avg power≈ 23 W / cabinet

Max power≈ 68 W / cabinet

IP ratingIP30 (indoor)

Lifespan100,000 hrs

Applications

Meeting roomsHuddle spacesTraining roomsExecutive offices

FAQ

All-in-one or custom fine pitch?

All-in-one suits standard rooms and installs fastest; custom fine pitch suits non-standard wall sizes.

Will it look sharp?

Viewing distance & image quality

Minimum viewing distance

1.2 m

Closest a viewer should stand

Comfortable distance

3 m

Where the image looks its best

Pixels per m²

694,444

Density at this pitch

Brightness

600 nits

Comfortable indoors

Rule of thumb: minimum viewing distance in metres \u2248 pixel pitch in millimetres. Final figures confirmed on site survey.

What you actually receive

A complete system, not just panels

LED cabinets & modules

Evolve AIO 1.2 · 600×337.5 mm

Control system

NovaStar MX30 + receiving cards

Power & data cabling

Looms, distribution and redundancy

Mounting structure

Wall frame, floor stand or truss

Spare modules & PSU

Held in Kathmandu for fast swap

Commissioning

Calibration, content test, handover training

How we deliver it

Site survey

We measure the space, power and sightlines — free across Nepal.

Structure & install

Fabrication, mounting and cabling by our certified engineers.

Commissioning

Calibration, controller setup and operator training.

AMC & support

Annual maintenance with spares stocked locally.

Warranty

Up to 3 years

Honoured locally in Nepal

Indicative lead time

2\u20134 weeks

Ex-stock items ship faster

Certifications

CERoHSFCCISO 9001

Also consider

Evolve

E-P1.25 COB

The volume COB in our range: specified for meeting rooms and smaller ops floors where 0.9 mm is more than the room needs.

P1.25indoor

Evolve

E-P0.9 COB

Our own-brand 0.9 mm COB — factory-direct pricing with Evolve Tech carrying the warranty and spares here in Nepal.

P0.9indoor

Evolve

E-P1.5

Own-brand 1.5 mm: the same class of panel as the imports at a landed cost we control end to end.

P1.5indoor

Model	Pitch	Brightness	Use	Cabinet
Evolve AIO 1.2 (this model)	P1.2	600 nits	indoor	600\u00d7337.5 mm
Evolve E-P1.25 COB	P1.25	600 nits	indoor	600\u00d7337.5 mm
Evolve E-P0.9 COB	P0.9	600 nits	indoor	600\u00d7337.5 mm
Evolve E-P1.5	P1.5	800 nits	indoor	600\u00d7337.5 mm

The full Evolve line

Evolve product lines we supply

Evolve — our own-brand LED line: control-room fine pitch, indoor commercial, rental staging, weatherproof outdoor and fully custom special-shaped builds, at direct pricing with local support.

Fine Pitch (Control Rooms & Studios)

Evolve E-P0.9 · Evolve E-P1.25 · Evolve E-P1.56

3 models \u2192

Indoor Commercial

Evolve E-P1.5 · Evolve E-P1.8 · Evolve E-P2.5 · Evolve FS Plus

4 models \u2192

Rental Stage

Evolve E-P3.91 · Evolve E-P4.81 · Evolve R5 Arc Lock

3 models \u2192

Outdoor Advertising

Evolve E-P6 · Evolve E-P8 · Evolve E-P10

3 models \u2192

Creative & Custom

Evolve Transparent · Evolve Flexible · Evolve Ring · Evolve Sphere · +1 more

5 models \u2192

Need a drawing, availability or the manufacturer datasheet for Evolve AIO 1.2?

Talk to an engineer →
