Evolve · Fine Pitch COB — Control Rooms

Evolve E-P1.25 COB

Name: Evolve E-P1.25 COB
Brand: Evolve

The volume COB in our range: specified for meeting rooms and smaller ops floors where 0.9 mm is more than the room needs.

Full specifications Typical wall sizes

Full specifications, dimensions and contact details on one page.

Front · 1/6

Cabinet front elevation — emitter grid and module seams drawn to scale.

Manufacturer product photography. Photography of the delivered installation is included in every project handover.

Pixel pitch

P1.25

Brightness

600 nits

Refresh

3,840 Hz

Use

Indoor

How it connects

Your source to this wall

Every Evolve wall we supply ships as a complete signal chain \u2014 including the NovaStar control layer most suppliers leave for you to figure out.

How it connects

source

Source (PC / player / camera)

processor

NovaStar H Series

controller

Sending & receiving cards

wall

Evolve E-P1.25 COB

Engineering

Major features, part by part

Hover any numbered point to see what it does and why it matters on site.

Reference

Typical wall sizes

Cabinets, resolution, power and weight for common wall sizes built from the 600×337.5 mm Evolve cabinet at P1.25.

Target size	Cabinets	Resolution	Actual size	Avg power	Weight
3 × 2 m	5 × 6 (30)	2400 × 1620 (3.9 MP)	3.00 × 2.02 m	0.7 kW	210 kg
4 × 2.5 m	7 × 7 (49)	3360 × 1890 (6.4 MP)	4.20 × 2.36 m	1.1 kW	343 kg
5 × 3 m	8 × 9 (72)	3840 × 2430 (9.3 MP)	4.80 × 3.04 m	1.7 kW	504 kg
6 × 3.5 m	10 × 10 (100)	4800 × 2700 (13.0 MP)	6.00 × 3.38 m	2.3 kW	700 kg
8 × 4.5 m	13 × 13 (169)	6240 × 3510 (21.9 MP)	7.80 × 4.39 m	3.9 kW	1183 kg
10 × 6 m	17 × 18 (306)	8160 × 4860 (39.7 MP)	10.20 × 6.08 m	7.0 kW	2142 kg

Cabinet counts are rounded to whole cabinets, so the actual size differs slightly from the target. Power is the average draw; size the supply on peak. Confirm structural loading against the manufacturer datasheet.

Recommended controlNovaStar H SeriesBeyond a single COEX controller — modular chassis, specified on the input list.NovaStar H Series →

Why this model

COB durability

Chip-on-board surface resists knocks, dust and cleaning — built for 24/7 duty.

16-bit grayscale

Holds detail in dark scenes so operators read low-light data clearly.

Redundant power & data

N+1 backup keeps the wall alive if a supply or cable fails.

Specifications

Display

Pixel pitch1.25 mm

LED typeCOB (chip-on-board)

Brightness600 nits

Refresh rate3,840 Hz

Colour depth14–16-bit

Viewing angle160° / 160°

Cabinet

Cabinet size600 × 337.5 mm

Resolution / cabinet480 × 270

Weight7 kg

Service accessFront

MountingFixed indoor

Power & environment

Avg power≈ 23 W / cabinet

Max power≈ 68 W / cabinet

IP ratingIP30 (indoor)

Lifespan100,000 hrs

Applications

Control roomsCommand centresBroadcast studiosExecutive boardrooms

FAQ

Is it rated for 24/7 operation?

Yes — COB fine pitch is designed for continuous duty with redundant power and signal.

How close can operators sit?

Comfortably within 1–2 m at these pitches, which suits control-room desks.

Will it look sharp?

Viewing distance & image quality

Minimum viewing distance

1.25 m

Closest a viewer should stand

Comfortable distance

3.1 m

Where the image looks its best

Pixels per m²

640,000

Density at this pitch

Brightness

600 nits

Comfortable indoors

Rule of thumb: minimum viewing distance in metres \u2248 pixel pitch in millimetres. Final figures confirmed on site survey.

What you actually receive

A complete system, not just panels

LED cabinets & modules

Evolve E-P1.25 COB · 600×337.5 mm

Control system

NovaStar H Series + receiving cards

Power & data cabling

Looms, distribution and redundancy

Mounting structure

Wall frame, floor stand or truss

Spare modules & PSU

Held in Kathmandu for fast swap

Commissioning

Calibration, content test, handover training

How we deliver it

Site survey

We measure the space, power and sightlines — free across Nepal.

Structure & install

Fabrication, mounting and cabling by our certified engineers.

Commissioning

Calibration, controller setup and operator training.

AMC & support

Annual maintenance with spares stocked locally.

Warranty

Up to 3 years

Honoured locally in Nepal

Indicative lead time

2\u20134 weeks

Ex-stock items ship faster

Certifications

CERoHSFCCISO 9001

Also consider

Evolve

AIO 1.2

Own-brand all-in-one, delivered and commissioned by our own team in Kathmandu.

P1.2indoor

Evolve

E-P1.5

Own-brand 1.5 mm: the same class of panel as the imports at a landed cost we control end to end.

P1.5indoor

Evolve

AIO 1.5

Our volume all-in-one for offices replacing an ageing projector and screen.

P1.5indoor

Model	Pitch	Brightness	Use	Cabinet
Evolve E-P1.25 COB (this model)	P1.25	600 nits	indoor	600\u00d7337.5 mm
Evolve AIO 1.2	P1.2	600 nits	indoor	600\u00d7337.5 mm
Evolve E-P1.5	P1.5	800 nits	indoor	600\u00d7337.5 mm
Evolve AIO 1.5	P1.5	600 nits	indoor	600\u00d7337.5 mm

The full Evolve line

Evolve product lines we supply

Evolve — our own-brand LED line: control-room fine pitch, indoor commercial, rental staging, weatherproof outdoor and fully custom special-shaped builds, at direct pricing with local support.

Fine Pitch (Control Rooms & Studios)

Evolve E-P0.9 · Evolve E-P1.25 · Evolve E-P1.56

3 models \u2192

Indoor Commercial

Evolve E-P1.5 · Evolve E-P1.8 · Evolve E-P2.5 · Evolve FS Plus

4 models \u2192

Rental Stage

Evolve E-P3.91 · Evolve E-P4.81 · Evolve R5 Arc Lock

3 models \u2192

Outdoor Advertising

Evolve E-P6 · Evolve E-P8 · Evolve E-P10

3 models \u2192

Creative & Custom

Evolve Transparent · Evolve Flexible · Evolve Ring · Evolve Sphere · +1 more

5 models \u2192

Need a drawing, availability or the manufacturer datasheet for Evolve E-P1.25 COB?
