Evolve · Rental — Indoor Staging

Evolve E-P3.91 Rental

Name: Evolve E-P3.91 Rental
Brand: Evolve

Our own rental panel, stocked in Kathmandu — including standby units you can draw on mid-event.

Full specifications Typical wall sizes

Full specifications, dimensions and contact details on one page.

Front · 1/6

Cabinet front elevation — emitter grid and module seams drawn to scale.

Manufacturer product photography. Photography of the delivered installation is included in every project handover.

Pixel pitch

P3.91

Brightness

1,200 nits

Refresh

3,840 Hz

Use

Rental

How it connects

Your source to this wall

Every Evolve wall we supply ships as a complete signal chain \u2014 including the NovaStar control layer most suppliers leave for you to figure out.

How it connects

source

Source (PC / player / camera)

processor

NovaStar VX400

controller

Sending & receiving cards

wall

Evolve E-P3.91 Rental

Engineering

Major features, part by part

Hover any numbered point to see what it does and why it matters on site.

Reference

Typical wall sizes

Cabinets, resolution, power and weight for common wall sizes built from the 500×500 mm Evolve cabinet at P3.91.

Target size	Cabinets	Resolution	Actual size	Avg power	Weight
3 × 2 m	6 × 4 (24)	767 × 512 (0.4 MP)	3.00 × 2.00 m	0.9 kW	168 kg
4 × 2.5 m	8 × 5 (40)	1023 × 639 (0.7 MP)	4.00 × 2.50 m	1.5 kW	280 kg
5 × 3 m	10 × 6 (60)	1279 × 767 (1.0 MP)	5.00 × 3.00 m	2.3 kW	420 kg
6 × 3.5 m	12 × 7 (84)	1535 × 895 (1.4 MP)	6.00 × 3.50 m	3.2 kW	588 kg
8 × 4.5 m	16 × 9 (144)	2046 × 1151 (2.4 MP)	8.00 × 4.50 m	5.5 kW	1008 kg
10 × 6 m	20 × 12 (240)	2558 × 1535 (3.9 MP)	10.00 × 6.00 m	9.1 kW	1680 kg

Cabinet counts are rounded to whole cabinets, so the actual size differs slightly from the target. Power is the average draw; size the supply on peak. Confirm structural loading against the manufacturer datasheet.

Recommended controlNovaStar VX400Compact staging load — one box scales, switches and sends.NovaStar VX400 →

Why this model

Tool-free quick-lock

Cabinets latch and align in seconds — hours off your get-in.

Curve-lock

Angle cabinets to build concave or convex stage arcs.

Flight-case ready

Protected corners and cases survive repeat touring.

Specifications

Display

Pixel pitch3.91 mm

LED typeSMD

Brightness1,200 nits

Refresh rate3,840 Hz

Colour depth14–16-bit

Viewing angle160° / 160°

Cabinet

Cabinet size500 × 500 mm

Resolution / cabinet128 × 128

Weight7 kg

Service accessFront

MountingGround-stack or flown

Power & environment

Avg power≈ 38 W / cabinet

Max power≈ 113 W / cabinet

IP ratingIP65

Lifespan100,000 hrs

Applications

ConcertsWeddingsCorporate eventsConferences

FAQ

Do you offer dealer rates?

Yes — Nepal event companies and rental houses get partner pricing and priority turnaround.

Are standby panels available?

We hold standby stock so a failed cabinet never stops a show.

Will it look sharp?

Viewing distance & image quality

Minimum viewing distance

3.91 m

Closest a viewer should stand

Comfortable distance

9.8 m

Where the image looks its best

Pixels per m²

65,410

Density at this pitch

Brightness

1,200 nits

Comfortable indoors

Rule of thumb: minimum viewing distance in metres \u2248 pixel pitch in millimetres. Final figures confirmed on site survey.

What you actually receive

A complete system, not just panels

LED cabinets & modules

Evolve E-P3.91 Rental · 500×500 mm

Control system

NovaStar VX400 + receiving cards

Power & data cabling

Looms, distribution and redundancy

Mounting structure

Wall frame, floor stand or truss

Spare modules & PSU

Held in Kathmandu for fast swap

Commissioning

Calibration, content test, handover training

How we deliver it

Site survey

We measure the space, power and sightlines — free across Nepal.

Structure & install

Fabrication, mounting and cabling by our certified engineers.

Commissioning

Calibration, controller setup and operator training.

AMC & support

Annual maintenance with spares stocked locally.

Warranty

Up to 3 years

Honoured locally in Nepal

Indicative lead time

2\u20134 weeks

Ex-stock items ship faster

Certifications

CERoHSFCCISO 9001

Also consider

Evolve

Transparent 3.9

Own-brand transparent at 3.9 mm — the cost-effective way to light up a shopfront without losing the window.

P3.9indoor

Evolve

Sphere 4.0

Own-brand spherical and cylindrical builds at a budget that clears a Nepali fit-out.

P4indoor

Evolve

E-P4.81 Rental

Own-brand outdoor rental with local spares — no waiting on a Guangzhou shipment mid-season.

P4.81rental

Model	Pitch	Brightness	Use	Cabinet
Evolve E-P3.91 Rental (this model)	P3.91	1,200 nits	rental	500\u00d7500 mm
Evolve Transparent 3.9	P3.9	4,000 nits	indoor	1000\u00d7500 mm
Evolve Sphere 4.0	P4	1,200 nits	indoor	500\u00d7500 mm
Evolve E-P4.81 Rental	P4.81	4,500 nits	rental	500\u00d71000 mm

The full Evolve line

Evolve product lines we supply

Evolve — our own-brand LED line: control-room fine pitch, indoor commercial, rental staging, weatherproof outdoor and fully custom special-shaped builds, at direct pricing with local support.

Fine Pitch (Control Rooms & Studios)

Evolve E-P0.9 · Evolve E-P1.25 · Evolve E-P1.56

3 models \u2192

Indoor Commercial

Evolve E-P1.5 · Evolve E-P1.8 · Evolve E-P2.5 · Evolve FS Plus

4 models \u2192

Rental Stage

Evolve E-P3.91 · Evolve E-P4.81 · Evolve R5 Arc Lock

3 models \u2192

Outdoor Advertising

Evolve E-P6 · Evolve E-P8 · Evolve E-P10

3 models \u2192

Creative & Custom

Evolve Transparent · Evolve Flexible · Evolve Ring · Evolve Sphere · +1 more

5 models \u2192

Need a drawing, availability or the manufacturer datasheet for Evolve E-P3.91 Rental?

Talk to an engineer →
